Method

Duality-based TV-L1 [DB-TV-L1]
http://gpu4vision.icg.tugraz.at/index.php?content=downloads.php

Submitted on 18 Sep. 2015 12:32 by
Moritz Menze (Leibniz Universität Hannover)

Running time:16 s
Environment:1 core @ 2.5 Ghz (Matlab)

Method Description:
In this work we therefore utilize an energy
functional which is based on Total Variation
regularization and a robust data term. We propose a
novel, fast and stable numerical scheme to find the
minimizer of this energy. Our approach combines a
fixed-point procedure derived from duality
principles combined with a fast thresholding step.
Parameters:
use_structure_texture = 1;
structure_texture_sigma = 1.0;
structure_texture_factor = 0.8;
lambda = 70.0;
theta = 0.25;
epsilon = 0.1;
maxits = 10;
max_pyramid_levels = 1000;
pyramid_factor = 0.5;
warps = 5;
Latex Bibtex:
@INPROCEEDINGS{Zach2007GCPR,
author = {C. Zach and T. Pock and H. Bischof},
title = {A Duality Based Approach for Realtime TV-
L1 Optical Flow},
pages = {214-223},
year = {2007},
booktitle = {DAGM}
}

Detailed Results

This page provides detailed results for the method(s) selected. For the first 20 test images, the percentage of erroneous pixels is depicted in the table. We use the error metric described in Object Scene Flow for Autonomous Vehicles (CVPR 2015), which considers a pixel to be correctly estimated if the disparity or flow end-point error is <3px or <5% (for scene flow this criterion needs to be fulfilled for both disparity maps and the flow map). Underneath, the left input image, the estimated results and the error maps are shown (for disp_0/disp_1/flow/scene_flow, respectively). The error map uses the log-color scale described in Object Scene Flow for Autonomous Vehicles (CVPR 2015), depicting correct estimates (<3px or <5% error) in blue and wrong estimates in red color tones. Dark regions in the error images denote the occluded pixels which fall outside the image boundaries. The false color maps of the results are scaled to the largest ground truth disparity values / flow magnitudes.

Test Set Average

Error Fl-bg Fl-fg Fl-all
All / All 47.52 48.27 47.64
All / Est 47.52 48.27 47.64
Noc / All 38.67 44.94 39.81
Noc / Est 38.67 44.94 39.81
This table as LaTeX

Test Image 0

Error Fl-bg Fl-fg Fl-all
All / All 25.67 90.69 34.59
All / Est 25.67 90.69 34.59
Noc / All 18.00 90.69 29.02
Noc / Est 18.00 90.69 29.02
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 1

Error Fl-bg Fl-fg Fl-all
All / All 29.72 54.03 32.43
All / Est 29.72 54.03 32.43
Noc / All 21.95 54.03 25.91
Noc / Est 21.95 54.03 25.91
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 2

Error Fl-bg Fl-fg Fl-all
All / All 46.44 26.96 45.50
All / Est 46.44 26.96 45.50
Noc / All 35.45 26.96 34.95
Noc / Est 35.45 26.96 34.95
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 3

Error Fl-bg Fl-fg Fl-all
All / All 65.06 96.39 67.96
All / Est 65.06 96.39 67.96
Noc / All 57.16 95.19 60.44
Noc / Est 57.16 95.19 60.44
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 4

Error Fl-bg Fl-fg Fl-all
All / All 50.62 93.45 57.73
All / Est 50.62 93.45 57.73
Noc / All 41.22 93.22 50.94
Noc / Est 41.22 93.22 50.94
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 5

Error Fl-bg Fl-fg Fl-all
All / All 38.05 0.14 34.64
All / Est 38.05 0.14 34.64
Noc / All 28.57 0.14 25.65
Noc / Est 28.57 0.14 25.65
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 6

Error Fl-bg Fl-fg Fl-all
All / All 45.20 2.01 40.65
All / Est 45.20 2.01 40.65
Noc / All 37.94 2.01 33.66
Noc / Est 37.94 2.01 33.66
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 7

Error Fl-bg Fl-fg Fl-all
All / All 3.07 100.00 22.04
All / Est 3.07 100.00 22.04
Noc / All 3.07 100.00 21.19
Noc / Est 3.07 100.00 21.19
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 8

Error Fl-bg Fl-fg Fl-all
All / All 4.17 100.00 21.87
All / Est 4.17 100.00 21.87
Noc / All 4.17 100.00 21.87
Noc / Est 4.17 100.00 21.87
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 9

Error Fl-bg Fl-fg Fl-all
All / All 2.66 99.83 27.48
All / Est 2.66 99.83 27.48
Noc / All 2.66 99.83 27.48
Noc / Est 2.66 99.83 27.48
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 10

Error Fl-bg Fl-fg Fl-all
All / All 44.42 63.95 48.87
All / Est 44.42 63.95 48.87
Noc / All 35.04 63.95 42.55
Noc / Est 35.04 63.95 42.55
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 11

Error Fl-bg Fl-fg Fl-all
All / All 38.53 50.80 40.73
All / Est 38.53 50.80 40.73
Noc / All 30.29 50.75 34.41
Noc / Est 30.29 50.75 34.41
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 12

Error Fl-bg Fl-fg Fl-all
All / All 54.17 50.24 53.90
All / Est 54.17 50.24 53.90
Noc / All 45.37 50.24 45.75
Noc / Est 45.37 50.24 45.75
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 13

Error Fl-bg Fl-fg Fl-all
All / All 53.66 100.00 59.35
All / Est 53.66 100.00 59.35
Noc / All 44.07 100.00 50.57
Noc / Est 44.07 100.00 50.57
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 14

Error Fl-bg Fl-fg Fl-all
All / All 50.25 6.91 49.50
All / Est 50.25 6.91 49.50
Noc / All 40.59 6.91 39.89
Noc / Est 40.59 6.91 39.89
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 15

Error Fl-bg Fl-fg Fl-all
All / All 72.10 53.41 70.41
All / Est 72.10 53.41 70.41
Noc / All 64.48 53.41 63.20
Noc / Est 64.48 53.41 63.20
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 16

Error Fl-bg Fl-fg Fl-all
All / All 57.61 99.98 63.85
All / Est 57.61 99.98 63.85
Noc / All 46.18 99.98 55.85
Noc / Est 46.18 99.98 55.85
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 17

Error Fl-bg Fl-fg Fl-all
All / All 65.23 82.18 66.99
All / Est 65.23 82.18 66.99
Noc / All 55.81 82.18 59.23
Noc / Est 55.81 82.18 59.23
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 18

Error Fl-bg Fl-fg Fl-all
All / All 61.42 100.00 79.75
All / Est 61.42 100.00 79.75
Noc / All 48.43 100.00 62.65
Noc / Est 48.43 100.00 62.65
This table as LaTeX

Input Image

Flow Result

Flow Error


Test Image 19

Error Fl-bg Fl-fg Fl-all
All / All 64.59 87.88 67.23
All / Est 64.59 87.88 67.23
Noc / All 53.06 87.88 58.10
Noc / Est 53.06 87.88 58.10
This table as LaTeX

Input Image

Flow Result

Flow Error
