Method

ByeongJun Network [BJN]


Submitted on 15 Sep. 2021 15:31 by
ByeongJun Yu (CBNU AVL)

Running time:0.02 s
Environment:1 core @ 2.5 Ghz (C/C++)

Method Description:
Transform data to the BEV plane.
Parameters:
\alpha=0.2
Latex Bibtex:

@Article{s21227623,
AUTHOR = {Yu, Byeongjun and Lee, Dongkyu and Lee,
Jae-Seol and Kee, Seok-Cheol},
TITLE = {Free Space Detection Using Camera-LiDAR
Fusion in a Bird’s Eye View Plane},
JOURNAL = {Sensors},
VOLUME = {21},
YEAR = {2021},
NUMBER = {22},
ARTICLE-NUMBER = {7623},
URL = {https://www.mdpi.com/1424-8220/21/22/7623},
PubMedID = {34833698},
ISSN = {1424-8220},

Evaluation in Bird's Eye View


Benchmark MaxF AP PRE REC FPR FNR
UM_ROAD 94.17 % 89.16 % 94.95 % 93.41 % 2.26 % 6.59 %
UMM_ROAD 96.29 % 93.98 % 98.14 % 94.52 % 1.97 % 5.48 %
UU_ROAD 93.13 % 87.59 % 93.89 % 92.38 % 1.96 % 7.62 %
URBAN_ROAD 94.89 % 90.63 % 96.14 % 93.67 % 2.07 % 6.33 %
This table as LaTeX

Behavior Evaluation


Benchmark PRE-20 F1-20 HR-20 PRE-30 F1-30 HR-30 PRE-40 F1-40 HR-40
This table as LaTeX

Road/Lane Detection

The following plots show precision/recall curves for the bird's eye view evaluation.


Distance-dependent Behavior Evaluation

The following plots show the F1 score/Precision/Hitrate with respect to the longitudinal distance which has been used for evaluation.


Visualization of Results

The following images illustrate the performance of the method qualitatively on a couple of test images. We first show results in the perspective image, followed by evaluation in bird's eye view. Here, red denotes false negatives, blue areas correspond to false positives and green represents true positives.



This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png

This figure as: png
